Physical

  • Height:
    3.0” (76.2 mm)
  • Width:
    2.5” (63.5 mm)
  • Depth:
    3.938” (100.0 mm)
  • Weight:
    2.5 lbs (1.13 kg)

Environmental

  • Operating temperature:
    36°F … 122°F (2° … 50°C)
  • Operating humidity:
    <80% RH at 5°C … 30°C,
    <50% at 31°C … 50°C
  • Storage temperature:
    – 27°F … 160°F (– 33°C … 71°C)

Mechanical

  • Operation:
    Any orientation
  • Mounting configuration:
    At bottom as well as on the face plate
  • Multiple Valve Choices:
    Valve type - 2 way to 12 way
  • Pressure Rating:
    100psi
  • Driver/Control board:
    Fully functional motor drivers and control electronics

Electrical and Communication

  • Inputs:
    2 Analog/Digital
  • Outputs:
    3 digital outputs
  • Communication Options:
    RS232, RS485 and CANbus
  • Power Requirement:
    24VDC
  • Power Consumption:
    20 Watts max, 5 watts idle

Compliance
REACH & RoHS Compliant
UL & CE Compliant
CSA Certified
EN 61326-1:2013
BS EN/EN IEC 61326-1:2021
IEC 61326-1:2020
