• Medium:
    Neutral or aggressive gases and liquids
  • Operation:
    Direct acting 3-way media separated valves
  • Operating pressure:
    Orifice 1.2 mm: -0.95…4.5 bar
    (-13.8…65.2 psi)
    Orifice 1.6 mm: -0.95…2.2.bar
    (-13.8…31.9 psi)
  • Flow:
    kv: 0.6 l/min; flow: 24 l/min (orifice
    1.2 mm, at Δp = 2 bar, 20°C (+68°F) )
    kv: 0.8 l/min; flow: 33 l/min (orifice
    1.6 mm, at Δp = 2 bar, 20°C (+68°F) )
  • Mounting:
    Manifold
  • Orifice:
    1,2 and 1,6 mm
  • Life expectancy:
    ≥10 Mio. cycles
  • Weight:
    30 g (1.06 lbs)
  • Ambient/media temperature:
    +5 ... +50 °C (+41 ... +122°F)
    Air supply must be dry enough to avoid ice formation at temperatures below +2 °C (+35°F).
  • Materials:
    Body in contact with media: PEEK
    Seal and diaphragm material in contact with media: FPM, FFPM, EPDM
