• Medium:
      Air, oxygen, neutral gases (10% to 95% humidity, non condensing), 40 μm filtered
    • Operation:
      Direct acting 2-way and 3-way valves, normally closed and normally opened
    • Flow:
      6 … 120 l/min at 2 bar (29 psi) at +20°C (+68°F)
    • kv factor:
      0,15 … 3 (Cv: 0,01 … 0,2)
    • Mounting:
      Manifold
    • Orifice:
      2/2 way valves: 0,5 … 3,6 mm (0,02 … 0,14”)
      3/2 way valves: 0,5 … 1,5 mm (0,02 … 0,06”)
    • Response time:
      10 … 15 ms
      Response time measured according to ISO 12238
    • Life expectancy:
      ≥100 million cycles (except Hit & Hold valves)
    • Weight:
      30 g (0.07 lbs)
    • Ambient/media temperature:
      -10 ... +50 °C (+14 ... +122°F)
      Air supply must be dry enough to avoid ice formation at temperatures below +2 °C (+35°F).
    • Materials:
      Body: PPS, PA
      Seat seals: NBR, FPM
      Internal parts: Stainless steel, PAA
