• Environmental Operating Temperature:
    2ºC to 50ºC (36ºF to 122ºF)
  • Operating Humidity:
    <80% Relative Humidity at 5°C to 30°C and <50% at 31°C to 50°C
  • Storage Temperature:
    -33°C to 71°C (-27°F to 160°F)
  • Noise:
    < 55dBA
  • Lifetime:
    > 5.7 Million cycles [1 cycle = 1 full dispense and aspirate move]
  • Mechanical Operation:
    Any orientation
  • Mounting Holes:
    Bottom and Front
  • Resolutions:
    12K, 24K and 48K steps
  • Performance Speed:
    0.0625 - 10,000 steps/sec
  • Precision:
    0.50% CV at 1/10th dispense
    0.05% CV at full stroke
    dispense
  • Accuracy:
    ±0.3% at 1/10th dispense
    ±0.2% at full stroke dispense
  • Flow Rate:
    Min: 46.9nL/hr (with 10μL syringe)
    Max: 2.5mL/min (with 50mL syringe)
  • Full Dispense Time:
    Min: 1.2 secs (with 12K resolution)
    Max: 12,800 min (with 48K resolution)
  • Flow Accuracy:
    ±1%
  • Plunger Lift Force:
    120lbs force, 12K res.
    140lbs force, 24 and 48K res.
  • Electrical Connection:
    6 inputs - 2 Analog/Digital, 4 Digital
    4 digital outputs
    Tamper pin
  • Communication Options:
    RS-232, RS485, CANbus
  • Power Requirements:
    24VDC (± 5% allowance)
    (with a maximum power ripple of 720mv peak to peak).
  • Power Consumption:
    14 watts max; 3.5 watts idle.
  • Rotary Valve Options:
    up to 12-way
  • Syringe Options:
    10μl to 50mL
  • Compliance:
    REACH & RoHS Compliant
    UL & CE Compliant
    CSA Certified
