• Environmental Operating Temperature:
    2ºC to 50ºC (36ºF to 122ºF)
  • Operating Humidity:
    <80% Relative Humidity at 5°C to 30°C and <50% at 31°C to 50°C
  • Storage Temperature:
    -33°C to 71°C (-27°F to 160°F)
  • Noise:
    < 55dBA
  • Lifetime:
    > 5 Million cycles (Cadent 3)
    [1 cycle = 1 full dispense and aspirate move]
  • Mechanical Operation:
    Any orientation
  • Mounting Holes:
    Top and bottom
    Front face
  • Resolutions:
    6K, 12K and 24K steps
  • Performance Speed:
    0.0625 - 10,000 steps/sec
  • Precision:
    0.50% CV at 1/10th dispense
    0.05% CV at full stoke dispense
  • Accuracy:
    ±0.3% at 1/10th dispense
    ±0.2% at full stroke dispense
  • Flow Rate:
    Min: 0.008μL/min (with 50μL syringe)
    Max: 500mL/min (with 5mL syringe)
  • Full Dispense Time:
    Min: 0.6 secs (with 6K resolution)
    Max: 6400 mins (with 24K resolution)
  • Flow Accuracy:
    ±1%
  • Linearity:
    R > 0.9999
  • Electrical Connection:
    6 inputs - 2 Analog/Digital, 4
    Digital
    4 digital outputs
    Tamper pin
  • Communication Options:
    RS-232, RS485, CANbus
  • Power Requirements:
    24VDC (± 5% allowance) (with a maximum power ripple of 720mv peak to peak).
  • Power Consumption:
    32 watts max; 3 watts idle.
  • Accessory Options Solenoid Valve Options:
    FAS 3/2 Microsol MS (Media
    Separated) Isolation Valve
  • Rotary Valve Options:
    up to 12-way
  • Syringe Options:
    50μl to 5mL
  • Compliance:
    REACH & RoHS Compliant
    UL & CE Compliant
    CSA Certified
